GZBtech 120V RGB Neon Rope Light: Ultimate User Guide

Table of Contents

1. Product Overview
2. Key Specifications
3. Safety Warnings
4. Accessories Included
5. Step-by-Step Installation
   • Controller Setup
   • Cutting Instructions
   • Powering & Waterproofing
6. Remote Control Guide
7. Troubleshooting
8. Warranty & Support



1. Product Overview

GZBtech’s RGB neon rope lights offer vibrant color-changing effects for dynamic indoor/outdoor lighting. Features include:

• 16 Static Colors + 4 Dynamic Modes: Perfect for parties, signage, and decor.
• Cuttable Design: Customize every 1 meter (3.3 feet).
• IP65 Rating: Water-resistant (non-waterproof at connections).
• 360° Control: RF remote with a 20-meter range.



2. Key Specifications

• Voltage: AC120V
• Power Consumption: 2.6W per foot
• LED Type: 5050 SMD LEDs
• Max Run Length: 130 feet (40 meters)
• Controller Power: 400W
• Applications: Events, retail displays, architectural accents

Included Accessories:

• RGB controller & RF remote
• Aluminum mounting clips/channels
• End caps, heat shrink tubing



3. Safety Warnings

⚠️ Critical Guidelines:

• Do not cover lights—overheating may cause a fire.
• Unroll fully before use—coiled lights can melt.
• Cut only at 1-meter marks to avoid electrical hazards.
• Avoid water exposure—connections require manual waterproofing.
• Max 130ft per power supply to prevent overload.



4. Accessories Included

• RGB Controller: 400W capacity, supports group control.
• Aluminum Mounting Clips/Channels: For curved/straight installations.
• Heat Shrink Tubing & Silicone Adhesive: For waterproofing connections.



5. Step-by-Step Installation

Controller Setup

1. Disconnect power.
2. Connect the male/female connectors to the RGB controller.
3. Align pins with the “>” polarity mark on the strip.
4. Insert pins into the strip’s internal wires without over-pushing.
5. Test lights and adjust polarity by flipping the connector 180° if needed.



Remote Control Guide

Key Functions

• On/Off: Retains last used settings.
• Brightness Adjustment: +/- buttons.
• Color Selection: 16 static colors.
• Dynamic Modes: Flashing, fading, and strobe effects.

Remote Pairing

1. Disconnect controller power.
2. Hold the brightness+ button for 5 seconds.
3. Reconnect power—lights will flash to confirm pairing.





Cutting Instructions

1. Turn off the power.
2. Cut only at the 1-meter mark (marked with black dots).
3. Seal ends with waterproof end caps.
4. Reattach a controller to each cut segment.

Note: Cutting voids certifications. Use sharp scissors for clean cuts.



Waterproofing Connections

1. Apply silicone adhesive to exposed wires.
2. Cover joints with heat shrink tubing and seal with a heat gun.
3. Let the adhesive cure for 24 hours.

Warning: Non-recommended sealants (e.g., tape) void the warranty.



7. Troubleshooting

Issue	Solution
Lights Won’t Turn On	Check 120V outlet, fuse, or polarity.
Partial Dark Spots	Secure loose pin connections.
Remote Not Working	Replace remote batteries (2 AAA).
Water Damage	Reapply silicone sealant to joints.

8. Warranty & Support

• 1-Year Warranty: Covers defects in materials/workmanship.
• 24/7 Assistance:
  • Website: www.gzbtech.com
  • Email: info@gzbtech.com
