GZBtech 120V COB LED Neon Rope Light: Ultimate Guide for Installation & Safety

Table of Contents

  • Why COB LED Neon Rope Lights?
  • Key Features & Technical Specs
  • Safety Guidelines
  • Step-by-Step Installation
  • Troubleshooting Common Issues
  • Warranty & Customer Support



1. Why 120V COB LED Neon Rope Lights?

GZBtech’s COB LED neon rope lights are a game-changer for modern lighting projects. Ideal for homes, businesses, and creative displays, they offer:

  • Seamless Illumination: COB (Chip-on-Board) technology eliminates visible LED dots.
  • Flexible Design: Cut every 4.5cm (1.7 inches) for custom lengths.
  • IP65 Waterproof Rating: Perfect for indoor/outdoor use in wet conditions.


2. Key Features & Technical Specs

  1. Voltage: 120V
  2. Power Consumption: 10W/M
  3. Max Run Length: 50 meters (164 feet)
  4. LED Density: 286 LEDs/M
  5. Certifications: ETL Listed safety for USA&CA
  6. Best Applications: Accent lighting, signage, retail displays


3. Safety Guidelines for COB Neon Rope Lights

⚠️ Critical Tips:

  • Cut only at marked intervals to avoid electrical hazards.
  • Never submerge spliced connections—IP65 applies to non-cut sections only.
  • Unroll fully before powering to prevent overheating.
  • Do not exceed 50% load per power feed to avoid overload.



4. Step-by-Step Installation Guide

How to Cut COB LED Neon Rope Lights?

  1. Turn off power at the source.
  2. Use sharp scissors to cut strictly at 1.7-inch marks.
  3. Seal cut ends with waterproof end caps.
  4. Test the lights before permanent installation.

Note: Cutting voids ETL certification. Proceed only if necessary.

Powering & Splicing Instructions

  1. Connect to Power:
    • Insert the strip into the weld-free buckle until copper pins pierce the circuit.
    • Secure with end caps and test functionality.
  2. Join Two Strips:
    • Use splice connectors to align polarity (+/-).
    • Seal joints with heat shrink tubing for durability.

Waterproofing Connections

  1. Apply silicone adhesive to exposed wires.
  2. Slide heat shrink tubing over joints and seal with a heat gun.
  3. Allow 24 hours for the adhesive to fully cure.



5. Troubleshooting COB LED Neon Rope Lights

Issue Solution
Lights Not Turning On Verify 120V outlet and check polarity alignment.
Dark Sections Re-secure loose connections or replace damaged segments.
Flickering Ensure dimmer compatibility and a stable power supply.
Water Damage Reapply silicone sealant to compromised joints.





6. Warranty & Customer Support
